A52DW
UPCERA
-
A52DW
· One click switch dry/wet working mode
· Reliable 12 "capacitive touch screen operation, user-friendly UI
· Build-in solid water tank
· Integrated multi-station fixture, can process disk, titanium column (4 pcs), glass ceramic (5 pcs)
· Stable and powerful spindle ensures high precision results
· 24-hour non-stop machining
Materials
Device Parameters
Dimensions
490x550x750mm
Weight
105Kg
Voltage
220V/50Hz;110V/60Hz(optional)
Power
1.0 KW
Compatible Compressed
0.5~0.8MPa
Spindle Speed
80,000 rpm
Precision
<0.0lmm
Number of Bur
12
Cooling Type
Air cooling or Water cooling (Built-in water tank)
Tilt Angle
A axis:+360°,B axis:+35°
Materials
Zirconia,Glass ceramic, Pre-milled Ti base
PEEK,PMMA,Wax (Ф98.5mm,thickness of
10mm-35mm)
Miling Speed
Glass-ceramic (10~35 minutes/pc), Pre-Milled
abutment (25 minutes/pc),Zirconia/PEEK/
PMMA (10 minutes/pc), Wax (3 minutes/pc)
Framework(45 minutes/pc)
Application
Coping, crown, bridge, inlay, onlay, veneer, post-core crown,dentalframework, telescope
denture, customized abutment and the crown on it, the restoration above the implant
